Gpon module +9 db

Single-fiber bi-directional SFP transceiver with SC/UPC connector operates at TX 1490nm (+9~+10dBm launch power), RX 1310nm (-33~-35dBm sensitivity @ BER 10^-10), 30dB SMSR, and 8.2dB extinction ratio per ITU-T G.984.2. Metal housing with LC latch ensures EMI shielding and heat dissipation (0~70°C commercial temp). DDM monitoring via I2C reports TX bias, TX power, RX power, voltage, and temperature. Compatible with multi-vendor OLTs for long-haul GPON backbone connections to cabinets or direct ONT serving.
