Typically used in GPON/EPON networks, this node ensures high-quality video, data, and voice services across a single fiber. It is ideal for RF overlay systems and allows triple-play service over optical fiber with the 1550 nm wavelength.
🔧 Technical Specifications:
Parameter Specification
Optical Input Wavelength 1550 nm (CATV signal)
Optical Input Power Range -15 dBm to +2 dBm
Number of RF Outputs 3 (F-type connectors)
RF Output Level ≥ 75 dBμV (typical @ 0 dBm input)
RF Frequency Range 45–1000 MHz
C/N (Carrier-to-Noise) ≥ 50 dB
C/CTB, C/CSO ≥ 60 dB
Return Loss ≥ 14 dB
Connector Types SC/APC (optical), F-type (RF)
Power Supply External (no built-in power supply)
Power Consumption Passive, < 1 W or externally powered
Operating Temperature -20°C to +55°C
Mounting Type Compact wall-mountable design
✅ Key Features:
3 RF outputs for flexible distribution of optical CATV signals
Converts 1550 nm optical signals to RF for video/TV signal distribution
High optical sensitivity for reliable signal reception
Compact design fits in tight spaces for easy indoor installation
Supports triple-play services via RF overlay in PON systems
External powering required (no internal power supply) for energy efficiency
Compatible with standard SC/APC optical and F-type RF connectors
🛠️ Applications:
FTTH/FTTB deployments in small residential or commercial buildings
CATV distribution for homes, apartments, or small office buildings
RF overlay systems in GPON/EPON networks
Ideal for multi-room or multi-TV homes
Passive optical network (PON) where external powering is available
