Equipped with a high-sensitivity photodiode, integrated AGC (Automatic Gain Control), and an internal power supply (AC or DC), this node ensures consistent signal levels and excellent picture quality—even with variable input signal strength.
🔧 Technical Specifications:
Parameter Specification
Optical Input Wavelength 1100 – 1600 nm (typically 1550 nm)
Optical Input Power Range -8 dBm to +2 dBm
RF Output Ports 1 (F-type or IEC)
RF Output Level ≥ 75 dBμV (typical @ 0 dBm input)
Flatness ±1 dB (45~1000 MHz)
Return Loss ≥ 14 dB
C/N (Carrier-to-Noise) ≥ 50 dB
C/CTB, C/CSO ≥ 60 dB
Power Supply AC 110~240V, DC 12V or 5V (depending on model)
Power Consumption < 3 W
Dimensions ~120 x 80 x 25 mm (compact)
Connectors SC/APC or SC/UPC for optical; F-type for RF
✅ Key Features:
Compact optical receiver with 1 RF output
Converts optical CATV signals to RF (45–1000 MHz)
High optical sensitivity allows use in long-reach PON or RF overlay systems
Built-in AGC maintains consistent RF output even with fluctuating optical input
Integrated AC or DC power supply for plug-and-play use
LED indicators for power and optical signal status
Easy wall or shelf mounting
🛠️ Applications:
FTTH / FTTB last-mile termination
Optical CATV signal reception in homes and apartments
RF overlay systems in GPON/EPON networks
Triple-play service delivery (video, data, voice)
